User’s Manual of IGS-604HPT-M12
284
that are matched in static entries on the specific port.
Buttons
: Click to translate all dynamic entries to static entries.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.11 IP Source Guard Static Table
This page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11 appears.
Figure 4-12-11: Static IP Source Guard Table Screen Screenshot
T
he page includes the following fields:
Object Description
Check to de
lete the entry. It will be deleted during the next save.
 Delete
T
he logical port for the settings.
 Port
T
he VLAN ID for the settings.
 VLAN ID
Allo
wed Source IP address.
 IP Address
Allo
wed Source MAC address.
 MAC Address
Buttons
: Click to add a new entry to the Static IP Source Guard table.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
