4.15.3 Remote IP Ping Test
This page allows you to issue ICMP ping packets to troubleshoot IP connectivity issues on special port. After you press “Test”, 5
ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The page
refreshes automatically until responses to all packets are received, or until a timeout occurs. The ICMP Ping screen in Figure
4-15-3 appears.
Figure 4-15-3: Remote IP Ping Test Screenshot
The page includes the following fields:
Object Description
T
he logical port for the settings.
 Port
T
he destination IP Address.
 Remote IP Address
T
he payload size of the ICMP packet.
Values range from 8 bytes to 1400 bytes.
 Ping Size
Displ
ay the ping result.
 Result
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Clears the IP Address and the result of ping value.
