User’s Manual of IGS-604HPT-M12
340
4.18.5 RMON History Configuration
Configure RMON History table on this page. The entry index key is ID; screen in Figure 4-18-5 appears.
Figure 4-18-5: RMON History Configuration Screenshot
The page includes the following fields:
Object Description
Check to de
lete the entry. It will be deleted during the next save.
 Delete
Indicates th
e index of the entry. The range is from 1 to 65535.
 ID
Indicates the p
ort ID which wants to be monitored. If in stacking switch, the value
must add 1000*(switch ID-1), for example, if the port is switch 3 port 5, the value
is 2005.
 Data Source
Indicates th
e interval in seconds for sampling the history statistics data.
The range is from 1 to 3600, default value is 1800 seconds.
 Interval
Indicates the m
aximum data entries associated this History control entry stored in
RMON.
The range is from 1 to 3600, default value is 50.
 Buckets
T
he number of data will be saved in the RMON.
 Buckets Granted
Buttons
: Click to add a new community entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
