User’s Manual of IGS-604HPT-M12
94
4.4.2 Port Statistics Overview
This page provides an overview of general traffic statistics for all switch ports. The Port Statistics Overview screen in Figure
4-4-2 appears.
Figure 4-4-2: Port Statistics Overview Screenshot
The displayed counters are:
Object Description
 Port
The logical port for the settings contained in the same row.
 Packets
The number of received and transmitted packets per port.
 Bytes
The number of received and transmitted bytes per port.
 Errors
The number of frames received in error and the number of incomplete
transmissions per port.
 Drops
The number of frames discarded due to ingress or egress congestion.
 Filtered
The number of received frames filtered by the forwarding process.
Buttons
: Download the Port Statistics Overview result as EXECL file.
: Click to refresh the page immediately.
: Clears the counters for all ports.
: Print the Port Statistics Overview result.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
