Planet IGS-604HPT-M12 User Manual

User’s Manual of IGS-604HPT-M12
78
Figure 4-2-29: Software Image Selection Screenshot
The page includes the following fields:
Object Description
 Image
The flash index name of the firmware image. The name of primary (preferred)
image is image, the alternate image is named image.bk.
 Version
The version of the firmware image.
 Date
The date where the firmware was produced.
Buttons
: Click to use the alternate image. This button may be disabled depending on system state.
4.2.25 Factory Default
You can reset the configuration of the Industrial Managed Switch on this page. Only the IP configuration is retained. The new
configuration is available immediately, which means that no restart is necessary. The Factory Default screen in Figure 4-2-30
appears.
Figure 4-2-30: Factory Default Screenshot

Planet IGS-604HPT-M12 Specifications

General

Brand	Planet
Model	IGS-604HPT-M12
Category	Network Router
Language	English
