4.20.5 Ring Wizard
This page allows the user to configure the ERPS by wizard; screen in Figure 4-20-4 appears.
Figure 4-20-5: Ring Wizard Screenshot
The page includes the following fields:
Object Description
Set all the s
witch numbers for the ring group. The default number is 3 and
maximum number is 30.
 All Switch Numbers
T
he switch where you are requesting ERPS.
 Number ID
Confi
gures the port number for the MEP.
 Port
Set the ERPS VLAN.
 VL
AN
Buttons
: Click to configure ERPS.
: Click to save changes.
: Click to show the ring topology.
