User’s Manual of IGS-604HPT-M12
195
DSCP
at Ingress side can be translated to any of (0-63) DSCP values.
ï‚· Translate
Click to en
able Classification at Ingress side.
ï‚· Classify
T
here are the following configurable parameters for Egress side –
Remap DP0 Controls the remapping for frames with DP level 0.
Remap DP1 Controls the remapping for frames with DP level 1.
ï‚· Eg
ress
Select the DS
CP value from select menu to which you want to remap. DSCP
value ranges from 0 to 63.
ï‚· Remap DP0
Select the DS
CP value from select menu to which you want to remap. DSCP
value ranges from 0 to 63.
ï‚· Remap DP1
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.9.10 DSCP Classification
This page allows you to map DSCP value to a QoS Class and DPL value. The DSCP Classification screen in Figure 4-9-11
appears.
Figure 4-9-11: DSCP Classification Screenshot
