User’s Manual of IGS-604HPT-M12
223
4.10.5 ACL Rate Limiter Configuration
Configure the rate limiter for the ACL of the switch.
The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears.
Figure 4-10-5: ACL Rate Limiter Configuration Screenshot
The page includes the following fields:
Object Description
T
he rate limiter ID for the settings contained in the same row.
 Rate Limiter ID
The allowed values are: 0-3276700 in pps or 0, 100, 200, 300, ..., 1000000 in kbps.
 Rate (pp
s)
S
pecify the rate unit. The allowed values are:
 Unit
 pps: packets per second.
 kbps: Kbits per second.
All means all ports will have one specific setting.
