Page #79 background imageLoading...
Page #79 background image
User’s Manual of IGS-604HPT-M12
79
Buttons
: Click to reset the configuration to Factory Defaults.
: Click to return to the Port State page without resetting the configuration.
To reset the Industrial Managed Switch to the Factory default setting, you can also press the hardware
reset button on the front panel for about 10 seconds. After the device is rebooted, you can login the
management Web interface within the same subnet of 192.168.0.xx.
4.2.26 System Reboot
The Reboot page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, users have to
re-login the Web interface for about 60 seconds later as the System Reboot screen in Figure 4-2-31 appears.
Figure 4-2-31: System Reboot Screenshot
Buttons
: Click to reboot the system.
: Click to return to the Port State page without rebooting the system.
You can also check the SYS LED on the front panel to identify whether the System is loaded completely or
not. If the SYS LED is blinking, then it is in the firmware load stage; if the SYS LED light is on, you can use
the Web browser to login the Industrial Managed Switch.
