1.5 Product Specifications
Product IGS-604HPT-M12
Hardware Specifications
Copper Ports
6 x M12, 8-pin A-Coded female connector, 10/100/1000BASE-T
auto-MDI/MDI-X ports
PoE Injector Port
4 ports with 802.3at/af PoE injector function (Port-3 to Port-6)
Power Connector
1 x M12, 5-pin A-Coded male connector
Switch Architecture
Store-and-Forward
Switch Fabric
12Gbps/non-blocking
Throughput
8.9Mpps@64bytes
Address Table
8K entries, automatic source address learning and aging
Shared Data Buffer
4M bits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
9K bytes
Dimensions (W x D x H)
103 x 68.2 x 163 mm
Weight
1069g
Enclosure
IP67 aluminum case
Installation
Wall-mount kit and DIN rail kit
LED
System:
PWR1 (Green), PWR2 (Green), Fault (Red)
Ring (Green), R.O. (Green)
10/100/1000T RJ45 Interfaces (Port 1 to Port 2):
LNK/ACT (Green)
10/100/1000T RJ45 Interfaces (Port 3 to Port 6):
LNK/ACT (Green)
PoE-in-Use (Orange)
Power Consumption
Max. 165.3 watts/563.7 BTU
Power Requirements
Dual 48~56V DC (>53V DC for PoE+ output recommended)
ESD Protection
6KV DC
Power over Ethernet
PoE Standard IEEE 802.3af/802.3at PoE/PSE
PoE Power Supply Type End-span
PoE Power Output
IEEE 802.3af Standard
- Per port 48V~53V DC (depending on the power supply), max. 15.4
watts
IEEE 802.3at Standard
- Per port 53V~56V DC (depending on the power supply), max. 36 watts
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Budget
144 watts max. (depending on power input)
PD @ 7 watts 4 units
PD @ 15.4 watts 4 units
PoE Ability
PD @ 30.8 watts 4 units
