4.16.3 Power Over Ethernet Configuration
This section allows the user to inspect and configure the current PoE configuration settings as Figure 4-16-2 appears.
Figure 4-16-2: PoE Configuration Screenshot
The page includes the following fields:
Object Description
Allo
ws user to enable or disable PoE function. It will cause all of PoE ports to
supply or not supply power.
System PoE Admin
Mode
Allo
ws user to enable or disable PoE Temperature Protection.
PoE Temperature
Protection
T
here are two modes for configuring how the ports/PDs may reserve power and
when to shut down ports.
Consumption mode: System offers PoE power according to PD real power
consumption.
Allocation mode: Users are allowed to assign how much PoE power for
each port and system will reserve PoE power to PD.
PoE Ma
nagement
Mode
Power Supply Budget
[W]
Set limit value of the total PoE port providing power to the PDs.
IGS-604HPT-M12 available maximum value is 144 watts.
Allo
ws setting over temperature protection threshold value. If Its system
temperature is over the threshold, the system will lower total PoE power budget
automatically.
Temperature
Threshold
PoE Usage Threshold
Allows setting how much PoE power budget could be limited.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
