User’s Manual of IGS-604HPT-M12
361
Instance State:
Object Description
ERPS st
ate according to State Transition Tables in G.8032.
 Protection State
OK: S
tate of East port is ok
SF: State of East port is Signal Fail
 Port 0
OK: S
tate of West port is ok
SF: State of West port is Signal Fail
 Port 1
T
he transmitted APS according to State Transition Tables in G.8032.
 Transmit APS
T
he received APS on Port 0 according to State Transition Tables in G.8032.
 Port 0 Receive APS
T
he received APS on Port 1 according to State Transition Tables in G.8032.
 Port 1 Receive APS
Remai
ning WTR timeout in milliseconds.
 WTR Remaining
APS is received on the
working flow.
 RPL Un-blocked
RAPS PDU is not receiv
ed from the other end.
 No APS Received
Block st
atus for Port 0 (Both traffic and R-APS block status). R-APS channel is
never blocked on sub-rings without virtual channel.
 Port 0 Block Status
Block st
atus for Port 1 (Both traffic and R-APS block status). R-APS channel is
never blocked on sub-rings without virtual channel.
 Port 1 Block Status
F
ailure of Protocol Defect (FOP) status. If FOP is detected, red LED will glow, or
else green LED will glow.
 FOP Alarm
Buttons
: Click to save changes.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 6 seconds.
: Click to refresh the page immediately.
: Click to undo any changes made locally and revert to previously saved values.
