User’s Manual of IGS-604HPT-M12
19
 Up to 255 VLANs groups, out of 4095 VLAN IDs
 Provides Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
 Private VLAN Edge (PVE)
 Protocol-based VLAN
 MAC-based VLAN
 IP subnet-based VLAN
 Voice VLAN
 Supports Spanning Tree Protocol
 IEEE 802.1D Spanning Tree Protocol (STP)
 IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
 IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN
 BPDU Guard
 Supports Link Aggregation
 802.3ad Link Aggregation Control Protocol (LACP)
 Cisco ether-channel (static trunk)
 Maximum 3 trunk groups, with 2 ports for each trunk
 Up to 4Gbps bandwidth (full duplex mode)
 Provides port mirror (many-to-1)
 Port mirroring monitors the incoming or outgoing traffic on a particular port
 Loop protection to avoid broadcast loops
 Supports E.R.P.S. (Ethernet Ring Protection Switching)
 IEEE 1588 and synchronous Ethernet network timing
 Quality of Service
 Ingress shaper and egress rate limit per port bandwidth control
 8 priority queues on all switch ports
 Traffic classification
- IEEE 802.1p CoS
- ToS/DSCP/IP precedence of IPv4/IPv6 packets
- IP TCP/UDP port number
- Typical network application
 Strict priority and Weighted Round Robin (WRR) CoS policies
 Traffic-policing policies on the switch port
 DSCP remarking
 Multicast
 Supports IGMP snooping v1, v2 and v3
 Supports MLD snooping v1 and v2
 Querier mode support
 IGMP snooping port filtering
 MLD snooping port filtering
 MVR (Multicast VLAN Registration)
