User’s Manual of IGS-604HPT-M12
192
 All: Classify all DSCP.
T
he Configuration All with available options will assign to whole ports.
Port Egress Rewriting can be one of –. All means all ports will have one specific
setting.
 Disable: No Egress rewrite.
 Enable: Rewrite enabled without remapping.
 Remap DP Unaware: DSCP from analyzer is remapped and frame is
remarked with remapped DSCP value. The remapped DSCP value is
always taken from the 'DSCP Translation->Egress Remap DP0' table.
 Remap DP Aware: DSCP from analyzer is remapped and frame is
remarked with remapped DSCP value. Depending on the DP level of the
frame, the remapped DSCP value is either taken from the 'DSCP
Translation->Egress Remap DP0' table or from the 'DSCP
Translation->Egress Remap DP1' table.
 Eg
ress
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
