User’s Manual of IGS-604HPT-M12

199

3. LLC

4. SNAP

5. IPv4

6. IPv6

Note: All frame types are explained below.

 Any

Allow all types of frames.

 EtherType

Ethernet Type Valid Ethernet type can have value within 0x600-0xFFFF or 'Any'

but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is 'Any'.

 LLC

■ SSAP Address Valid SSAP(Source Service Access Point) can vary from

0x00 to 0xFF or 'Any', the default value is 'Any'

■ DSAP Address Valid DSAP(Destination Service Access Point) can vary

from 0x00 to 0xFF or 'Any', the default value is 'Any'

■ Control Address Valid Control Address can vary from 0x00 to 0xFF or

'Any', the default value is 'Any'

 SNAP

PID Valid PID(a.k.a Ethernet type) can have value within 0x00-0xFFFF or 'Any',

default value is 'Any'

 IPv4

■ Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'

■ Source IP Specific Source IP address in value/mask format or 'Any'. IP and

Mask are in the format x.y.z.w where x, y, z, and w are decimal numbers

between 0 and 255. When Mask is converted to a 32-bit binary string and

read from left to right, all bits following the first zero must also be zero

■ DSCP Diffserv Code Point value(DSCP): It can be specific value, range of

value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7,

EF or AF11-AF43

■ IP Fragment IPv4 frame fragmented option: yes|no|any

■ Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range

applicable for IP protocol UDP/TCP

■ Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range

applicable for IP protocol UDP/TCP

 IPv6

■ Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'

■ Source IP IPv6 source address: (a.b.c.d) or 'Any', 32 LS bits

■ DSCP Diffserv Code Point value (DSCP): It can be specific value, range of
