User’s Manual of IGS-604HPT-M12
328
The screen in Figure 4-16-6 appears.
Figure 4-16-6: PoE Schedule Screenshot
Please press Add New Rule button to start settingPoE Schedule function. You have to set PoE schedule via profile and then go
back to PoE Port Configuration, and select “Schedule” mode from per port “PoE Mode” option and then you can indicate which
schedule profile could be apply to the PoE port.
The page includes the following fields:
Object Description
Set the sched
ule profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
 Profile
Allo
ws user to set week day for defining PoE function (should be enabled on the
day).
 Week Day
Allo
ws user to set at what hour PoE function starts when enabled.
 Start Hour
Allo
ws user to set at what minute PoE function starts when enabled.
 Start Min
Allo
ws user to set at what hour PoE function ends when disabled.
 End Hour
Allo
ws user to set at what minute PoE function ends when disabled.
 End Min
 Reboot Enable
Allows user to enable or disable whole PoE port reboot by PoE reboot schedule.
Please note that if you want PoE schedule and PoE reboot schedule to work at the
