Planet IGS-604HPT-M12 User Manual

User’s Manual of IGS-604HPT-M12
350
The page includes the following fields:
Object Description
Sho
ws the current One_pps_mode configured.
1. Output : Enable the 1 pps clock output
2. Input : Enable the 1 pps clock input
3. Disable : Disable the 1 pps clock in/out-put
 One_pps_mode
Sho
ws the current External clock output configuration.
1. True : Enable the external clock output
2. False : Disable the external clock output
 External Enable
Sho
ws the current VCXO rate adjustment configuration.
1. True : Enable the external VCXO rate adjustment
2. False : Disable the external VCXO rate adjustment
 VCXO_Enable
Sho
ws the current clock frequency used by the External Clock.
The possible range of values are 1 - 25000000 (1 - 25MHz)
 Clock Frequency
PTP Clock Description
Object Description
Indicates th
e Instance of a particular Clock Instance [0..3].
Click on the Clock Instance number to monitor the Clock details.
 Clock Instance
Indicates th
e Type of the Clock Instance. There are five Device Types.
1. Ord-Bound - Clock's Device Type is Ordinary-Boundary Clock.
2. P2p Transp - Clock's Device Type is Peer to Peer Transparent Clock.
3. E2e Transp - Clock's Device Type is End to End Transparent Clock.
4. Master Only - Clock's Device Type is Master Only.
5. Slave Only - Clock's Device Type is Slave Only.
 Device Type
Sho
ws the ports configured for that Clock Instance.
 Port List
Buttons
: Click to refresh the page immediately.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
