Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
21
1.4 Product Features
 Physical Port
 16 100/1000Base-X SFP mini-GBIC slots from port9 to port24
 8-Port 10/100/1000Base-T Gigabit Ethernet RJ-45
 RS-232 DB9 console interface for Switch basic management and setup
 Hardware Conformance
 36 to 72V DC, redundant power with polarity reverse protect function
 -10 to 60 Degree C operating temperature
 19-inch Rack-mountable
 Relay alarm for port breakdown, power failure
 Two Thermal FAN built-in
 Layer 2 Features
■ Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
■ High performance of Store-and-Forward architecture, broadcast storm control and runt/CRC filtering eliminates
erroneous packets to optimize the network bandwidth
■ Storm Control support:
 Broadcast / Multicast / Unknown-Unicast
■ Support VLAN
 IEEE 802.1Q Tagged VLAN
 Up to 255 VLANs groups, out of 4094 VLAN IDs
 Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
 Private VLAN Edge (PVE)
 Voice VLAN
■ Support Spanning Tree Protocol
 STP, IEEE 802.1D Spanning Tree Protocol
 RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
 MSTP, IEEE 802.1s Multiple Spanning Tree Protocol, spanning tree by VLAN
 BPDU Guard
■ Support Link Aggregation
 802.3ad Link Aggregation Control Protocol (LACP)
 Cisco ether-channel (Static Trunk)
 Maximum 12 trunk groups, up to 16 ports per trunk group
 Up to 32Gbps bandwidth(Duplex Mode)
■ Provide Port Mirror (many-to-1)
■ Port Mirroring to monitor the incoming or outgoing traffic on a particular port
 Quality of Service

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
