User’s Manual of MGSW-24160F
24
1.5 Product Specification
Product MGSW-24160F
Hardware Specification
SFP/mini-GBIC Slots
16 1000Base-SX/LX/BX SFP interfaces, from port9 to port16
Compatible with 100Base-FX SFP
Copper Ports
8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
Console Port
1 x RS-232 DB9 serial port (115200, 8, N, 1)
Switch Processing Scheme
Store-and-Forward
Switch Throughput@64Bytes 35.7Mpps
Switch Fabric
48Gbps / non-blocking
Address Table
8K entries, automatic source address learning and ageing
Share data Buffer
1392 kilobytes
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame
10Kbytes
Reset Button
< 5 seconds: System reboot
> 10 seconds: Factory Default
Dimension (W x D x H)
440 x 200 x 44.5 mm, 1U high
Weight
3kg
LED
Power, DC1, DC2, Fault, Link/Act and speed per Gigabit port
Power Consumption
Max. 45 Watts / 154.4 BTU (AC)
Power Requirement – AC
AC 100~240V, 50/60Hz 0.75A
Power Requirement – DC
-36V DC @ 1.1A, Range: -36V ~ -72V DC
DI/DO
2 Digital Input (DI): Level 0: -30~0V
Level 1: 0~30V
Max. input current: 8mA
2 Digital Output(DO): Open collector to 30VDC, 200mA
Layer 2 Function
Port configuration
Port disable / enable
Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Bandwidth control on each port
Power saving mode control
Port Status
Display each port’s speed duplex mode, link status, Flow control status.
Auto negotiation status, trunk status.
VLAN
802.1Q Tagged Based VLAN

Table of Contents

Other manuals for Planet MGSW-24160F

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet MGSW-24160F and is the answer not in the manual?

Planet MGSW-24160F Specifications

General IconGeneral
Console portRS-232
Compatible memory cardsNot supported
SFP module slots quantity16
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresPrivate VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supportedYes
Throughput35.6 Mpps
Jumbo frames10000
MAC address table16000 entries
Form factor1U
Product colorBlue
Number of fans2 fan(s)
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)38 W
Number of multicast groups filtered255
Switch typeManaged
Switch layerL2+
DHCP featuresDHCP server, DHCP client
Security algorithmsSNMP, SSH, SSL/TLS
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 60 °C
Operating relative humidity (H-H)5 - 95 %
Transmission distance (max)120 km
Fiber ethernet cabling technology1000BASE-X
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth200 mm
Width440 mm
Height44.5 mm
Weight3000 g
