User’s Manual of MGSW-24160F
272
 VLAN
The VLAN ID of the entry.
 MAC address
The MAC address of the entry.
 Port Members
The ports that are members of the entry.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input fields.
: Flushes all dynamic entries.
: Updates the table starting from the first entry in the MAC Table, i.e. the entry with the lowest VLAN ID and MAC
address.
: Updates the table, starting with the entry after the last entry currently displayed.
4.13.4 MAC Table Learning
If the learning mode for a given port is grayed out, another module is in control of the mode, so that it cannot be changed by the
user. An example of such a module is the MAC-Based Authentication under 802.1X.
Each port can do learning based upon the following settings:
Port security is a feature that allows you to configure a switch port with one or more device MAC addresses that are authorized
to access the network through that port.
When port security is enabled on a port, the Managed Switch stops learning new MAC addresses on the specified port and
when it has reached a configured maximum number. Only incoming traffic with source addresses already stored in the dynamic
or static address table will be authorized to access the network through that port. If a device with an unauthorized MAC address
attempts to use the switch port, the intrusion will be detected and the switch can automatically take action by disabling the port
and sending a trap message.
<source MAC address, VLAN> pair for frames received on the port.
Note that you can also manually add secure addresses to the port using the Static Address Table. The selected port will stop
learning. The MAC addresses already in the address table will be retained and will not age out. Any other device that attempts to
use the port will be prevented from accessing the switch. The MAC Table Learning screen in Figure 4-13-4 appears.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
