User’s Manual of MGSW-24160F
315
Enable IPv6 autoconfig function:
SWITCH/>ip ipv6 autoconfig enable
IPv6 Setup
Description:
Set or show the IPv6 setup.
Syntax:
IP IPv6 Setup [<ipv6_addr>] [<ipv6_prefix>] [<ipv6_router>] [<vid>]
Parameters:
<ipv6_addr> : IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon
separates each field (:). For example, four hexadecimal digits with a colon separates each field (:). For
example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special syntax that can be used as a shorthand
way of representing multiple 16-bit groups of contiguous zeros; but it can only appear once. It also used
a following legally IPv4 address.
For example,'::192.1.2.34'.
<ipv6_prefix>: IPv6 subnet mask , default: Show IPv6 prefix
<ipv6_router>: IPv6 router , default: Show IPv6 router.
IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a
colon separates each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special syntax
that can be used as a shorthand way of representing multiple 16-bit groups of contiguous zeros; but it
can only appear once. It also used a following legally IPv4 address. For example,'::192.1.2.34'.
<vid> : VLAN ID (1-4095), default: Show VLAN ID
Default Setting:
IPv6 AUTOCONFIG mode : Disabled
IPv6 Link-Local Address: fe80::230:4fff:fe24:4d1
IPv6 Address : ::192.168.0.100
IPv6 Prefix : 96
IPv6 Router : ::
IPv6 VLAN ID : 1
Example:
Set IPv6 address:
SWITCH/>ip ipv6 setup 2001::0002 64 2100::0001 1

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
