Page #370 background imageLoading...
Page #370 background image
User’s Manual of MGSW-24160F
370
Syntax:
Security Switch SNMP User Look up [<index>]
Parameters:
<index>: entry index (1-64)
Example:
Look up SNMPv3 user entry
SWITCH/>security switch snmp user lookup
Idx Engine ID User Name Level Auth Priv
--- --------- -------------------------------- -------------- ---- ----
1 Remote admin_snmpv3 Auth, Priv MD5 DES
Number of entries: 1
Security Switch SNMP Group Add
Description:
Add or modify SNMPv3 group entry.
The entry index key are <security_model> and <security_name>.
Syntax:
Security Switch SNMP Group Add <security_model> <security_name> <group_name>
Parameters:
<security_model>: v1 - Reserved for SNMPv1
v2c - Reserved for SNMPv2c
usm - User-based Security Model (USM)
<security_name> : A string identifying the security name that this entry should belong to
<group_name> : A string identifying the group name that this entry should belong to
Example:
Add SNMPv3 group entry
SWITCH/>security switch snmp group add usm admin_snmpv3 group_snmpv3
