Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
263
The page includes the following fields:
Object Description
 Rx and Tx Discover
The number of discover (option 53 with value 1) packets received and
transmitted.
 Rx and Tx Offer
The number of offer (option 53 with value 2) packets received and transmitted.
 Rx and Tx Request
The number of request (option 53 with value 3) packets received and transmitted.
 Rx and Tx Decline
The number of decline (option 53 with value 4) packets received and transmitted.
 Rx and Tx ACK
The number of ACK (option 53 with value 5) packets received and transmitted.
 Rx and Tx NAK
The number of NAK (option 53 with value 6) packets received and transmitted.
 Rx and Tx Release
The number of release (option 53 with value 7) packets received and transmitted.
 Rx and Tx Inform
The number of inform (option 53 with value 8) packets received and transmitted.
 Rx and Tx Lease Query
The number of lease query (option 53 with value 10) packets received and
transmitted.
 Rx and Tx Lease
Unassigned
The number of lease unassigned (option 53 with value 11) packets received and
transmitted.
 Rx and Tx Lease
Unknown
The number of lease unknown (option 53 with value 12) packets received and
transmitted.
 Rx and Tx Lease
Active
The number of lease active (option 53 with value 13) packets received and
transmitted.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
: Clears the counters for the selected port.
4.12.10 IP Source Guard Configuration
IP Source Guard is a secure feature used to restrict IP traffic on DHCP snooping untrusted ports by filtering traffic based on the
DHCP Snooping Table or manually configured IP Source Bindings. It helps prevent IP spoofing attacks when a host tries to
spoof and use the IP address of another host. This page provides IP Source Guard related configuration. The IP Source Guard

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
