Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
406
Security Network IP Source Guard Entry
Description:
Add or delete IP source guard static entry.
Syntax:
Security Network IP Source Guard Entry [<port_list>] add|delete <vid> <allowed_ip> <ip_mask>
Parameters:
<port_list> : Port list or 'all', default: All ports
add : Add new port IP source guard static entry
delete : Delete existing port IP source guard static entry
<vid> : VLAN ID (1-4095)
<allowed_ip>: IP address (a.b.c.d), IP address allowed for doing ARP request
<ip_mask> : IP mask (a.b.c.d), IP mask for allowed IP address
Example:
Add IP source guard static entry.
SWITCH/>security network ip source guard entry 1 add 1 192.168.0.20 255.255.255.0
Security Network IP Source Guard Status
Description:
Show IP source guard static and dynamic entries.
Syntax:
Security Network IP Source Guard Status [<port_list>]
Parameters:
<port_list>: Port list or 'all', default: All ports
Example:
Show IP source guard static and dynamic entries.
SWITCH/>security network ip source guard status

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
