Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
493
Syntax:
Di_desc [first|second] [<description>]
Parameters:
<first >: Digital input/output 1
<second>: Digital input/output 2
(default: Set or show digital input/output first(1)/second(2) select)
<description>: Digital input1/2 described string. Use 'clear' or "" to clear the string In CLI, no blank or space characters
are permitted as part of a contact.
Example:
Set digital input alarm message.
SWITCH/>dido di_desc first "window was opened!"
Di_en
Description:
Set or show the system digital input1/2.
Syntax:
di_desc [first|second] [<description>]
Parameters:
<first >: Digital input/output 1
<second>: Digital input/output 2
(default: Set or show digital input/output first(1)/second(2) select)
<enable>: Enable digital input1/2 function
<disable>: Disable digital input1/2 function
(default: Set or show digital input/output/fault alarm 1/2 status)
<hightolow>: Trigger -> high to low
<lowtohigh>: Trigger -> low to high
(default: Set or show digital input/output 1/2 trigger)
Example:
Enable digital input function and set trigger condition.
SWITCH/>dido di_en first enable hightolow

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
