Page #412 background imageLoading...
Page #412 background image
User’s Manual of MGSW-24160F
412
enable : Enable RADIUS authentication server
disable : Disable RADIUS authentication server
(default: Show RADIUS server mode)
<ip_addr_string>: IP host address (a.b.c.d) or a host name string
<secret> : Secret shared with external authentication server.
Set to empty secret, please use two quotes ("").
To use spaces in secret, enquote the secret.
Quotes in the secret are not allowed.
<server_port> : Server UDP port. Use 0 to use the default RADIUS port (1812)
Example:
Set RADIUS authentication server configuration.
SWITCH/>security aaa radius 1 enable 192.168.0.20 12345678 1812
Security AAA ACCT_RADIUS
Description:
Set or show RADIUS accounting server setup.
Syntax:
Security AAA ACCT_RADIUS [<server_index>] [enable|disable] [<ip_addr_string>] [<secret>] [<server_port>]
Parameters:
The server index (1-5)
(default: Show RADIUS accounting server configuration)
enable : Enable RADIUS accounting server
disable : Disable RADIUS accounting server
(default: Show RADIUS server mode)
<ip_addr_string>: IP host address (a.b.c.d) or a host name string
<secret> : Secret shared with external accounting server.
Set to an empty secret, use two quotes ("").
To use spaces in secret, enquote the secret.
Quotes in the secret are not allowed.
<server_port> : Server UDP port. Use 0 to use the default RADIUS port (1813)
Example:
Set RADIUS accounting server configuration.
SWITCH/>security acct_radius 1 enable 192.168.0.20 12345678 1813

Table of Contents

Other manuals for Planet MGSW-24160F

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet MGSW-24160F and is the answer not in the manual?

Planet MGSW-24160F Specifications

General IconGeneral
Console portRS-232
Compatible memory cardsNot supported
SFP module slots quantity16
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresPrivate VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supportedYes
Throughput35.6 Mpps
Jumbo frames10000
MAC address table16000 entries
Form factor1U
Product colorBlue
Number of fans2 fan(s)
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)38 W
Number of multicast groups filtered255
Switch typeManaged
Switch layerL2+
DHCP featuresDHCP server, DHCP client
Security algorithmsSNMP, SSH, SSL/TLS
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 60 °C
Operating relative humidity (H-H)5 - 95 %
Transmission distance (max)120 km
Fiber ethernet cabling technology1000BASE-X
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth200 mm
Width440 mm
Height44.5 mm
Weight3000 g
