User’s Manual of MGSW-24160F

4.2.17 Configuration Backup

This function allows backup and reload the current configuration of the Managed Switch to the local management station. The

Configuration Backup screen in Figure 4-2-21 appears.

Figure 4-2-21 Configuration Backup Page Screenshot

You can save/view or load the switch configuration. The configuration file is in XML format with a hierarchy of tags:

Header tags:

<?xml version="1.0"?> and <configuration>. These tags are mandatory and must be present

at the beginning of the file.

Section tags:

<platform>, <global> and <switch>. The platform section must be the first section tag and

this section must include the correct platform ID and version. The global section is optional

and includes configuration that is not related to specific switch ports. The switch section is

optional and includes configuration that is related to specific switch ports.

Module tags:

<ip>, <mac>, <port> etc. These tags identify a module controlling specific parts of the

configuration.

Group tags:

<port_table>, <vlan_table> etc. These tags identify a group of parameters, typically a table.

Parameter tags:

<mode>, <entry> etc. These tags identify parameters for the specific section, module and

group. The <entry> tag is used for table entries.

Configuration parameters are represented as attribute values. When saving the configuration from the switch, the entire

configuration including syntax descriptions is included in the file. The file may then be modified using an editor and loaded to a

switch.

The example is as below shows ismall configuration file only including configuration of the MAC address age time and the

learning mode per port. When loading this file, only the included parameters will be changed. This means that the age time will

be set to 200 and the learn mode will be set to automatic.

 Save Configuration

1. Press the “Save Configuration” button to save the current configuration in manager workstation. The following screens in

Figure 4-2-22 & 4-2-23 appear

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
