User’s Manual of MGSW-24160F
481
Parameters:
<oui_addr> : OUI address (xx-xx-xx)
<description>: Entry description. Use 'clear' or "" to clear the string
No blank or space characters are permitted as part of a contact.(only in CLI)
Example:
Add Voice VLAN OUI entry.
SWITCH/>voice vlan oui add 00-11-22 test
Voice VLAN OUI Delete
Description:
Delete Voice VLAN OUI entry.
Modify OUI table will restart auto detect OUI process.
Syntax:
Voice VLAN OUI Delete <oui_addr>
Parameters:
<oui_addr>: OUI address (xx-xx-xx)
Example:
Delete Voice VLAN OUI entry.
SWITCH/>voice vlan oui delete 00-11-22
Voice VLAN OUI Clear
Description:
Clear Voice VLAN OUI entry.
Modify OUI table will restart auto detect OUI process.
Syntax:
Voice VLAN OUI Clear
Example:
Clear Voice VLAN OUI entry.
SWITCH/>voice vlan oui clear

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
