User’s Manual of MGSW-24160F
304
6. Command Line Mode
The CLI groups all the commands in appropriate modes according to the nature of the command. A sample of the CLI command
modes are described below. Each of the command modes supports specific software commands.
Command Groups:
System System settings and reset options
IP IP configuration and Ping
Port Port management
MAC MAC address table
VLAN Virtual LAN
PVLAN Private VLAN
Security Security management
STP Spanning Tree Protocol
IGMP Internet Group Management Protocol snooping
Aggr Link Aggregation
LACP Link Aggregation Control Protocol
LLDP Link Layer Discovery Protocol
LLDPMED Link Layer Discovery Protocol Media
PoE Power Over Ethernet
QoS Quality of Service
Mirror Port mirroring
Config Load/Save of configuration via TFTP
Firmware Download of firmware via TFTP
UPnP Universal Plug and Play
MVR Multicast VLAN Registration
Voice VLAN Specific VLAN for voice traffic
SMTP SMTP control configure
Show Display the current information
6.1 System Command
System Configuration
Description:
Show system configuration.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
