The page includes the following fields:
Object Description
 VLAN ID
The VLAN ID of the entry.
 Groups
The present IGMP groups. Max. are 128 groups for each VLAN.
 Port Members
The ports that are members of the entry.
 Querier Status
Show the Querier status is "ACTIVE" or "IDLE".
 Querier Transmit
The number of Transmitted Querier.
 Querier Receive
The number of Received Querier.
 V1 Reports Receive
The number of Received V1 Reports.
 V2 Reports Receive
The number of Received V2 Reports.
 V3 Reports Receive
The number of Received V3 Reports.
 V2 Leave Receive
The number of Received V2 Leave.
Buttons
: Click to refresh the page immediately.
: Clears all Statistics counters.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
4.8.7 MVR Configuration
In multicast VLAN networks, subscribers to a multicast group can exist in more than one VLAN. If the VLAN boundary
restrictions in a network consist of Layer 2 switches
Multicast VLAN Registration (MVR) is a protocol for Layer 2 (IP)-networks that enables multicast-traffic from a source VLAN
to be share
d with subscriber-VLANs. The alternative would be to use PIM or a similar protocol to route the traffic through a
Layer 3- network, it might be necessary to replicate the multicast stream to the same gr
oup in different subnets, even if they are
on the same physical network. Multicast VLAN Registration (MVR) routes packets received in a multicast source VLAN to one or
more receive VLANs. Clients are in the receive VLANs and the multicast server is in the source VLAN. Multicast routing has to
be disabled when MVR is enabled. Refer to the configuration guide at Understanding Multicast VLAN Registration for more
information on MVR. MVR is typically used for IPTV-like services and is therefore usually only available on enterprise-level
switches. Many manufacturers provide support for MVR on their high-end switches.
The main reason for using MVR is to save bandwidth by preventing duplicate multicast streams being sent in the core network,
instead the stream(s) are received on the MVR-VLAN and forwarded to the VLANs where hosts have requested it/them.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
