User’s Manual of MGSW-24160F
353
snmp : SNMP interface
telnet : TELNET/SSH interface
(default: Show configured and current mode)
Example:
Add access management list from 192.168.0.1 to 192.168.0.200 via web interface.
SWITCH/>security switch access add 1 192.168.0.1 192.168.0.200 web
Security Switch Access IPv6 Add
Description:
Add access management IPv6 entry.
Syntax:
Security Switch Access Ipv6 Add <access_id> <start_ipv6_addr> <end_ipv6_addr> [web|snmp|telnet]
Parameters:
access_id> : entry index (1-16)
<start_ipv6_addr>: Start IPv6 address.
IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a
colon separate each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special
syntax that can be used as a shorthand way of representing multiple 16-bit groups of contiguous
zeros; but it can only appear once. It also used a following legally IPv4 address. For
example,'::192.1.2.34'.
<end_ipv6_addr> : End IPv6 address.
IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a
colon separate each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special
syntax that can be used as a shorthand way of representing multiple 16-bit groups of contiguous
zeros; but it can only appear once. It also used a following legally IPv4 address. For
example,'::192.1.2.34'.
web : WEB/HTTPS interface
snmp : SNMP interface
telnet : TELNET/SSH interface
(default: Show configured and current mode)
Example:
Add access management list from 2001::0001 to 2001::0100 via web interface.
SWITCH/> security switch access add 2001::0001 2001::0100 web

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
