Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
428
Default:
auto
Example:
Set MSTI2 in port1~2
SWITCH/>stp msti port configuration 2 1-2
MSTI Port Path Cost Priority
---- ---- ---------- --------
MST2 Aggr Auto 128
MSTI Port Path Cost Priority
---- ---- ---------- --------
MST2 1 Auto 128
MST2 2 Auto 128
STP MSTI Port Cost
Description:
Set or show the STP CIST/MSTI port path cost.
Syntax:
STP Msti Port Cost [<msti>] [<port_list>] [<path_cost>]
Parameters:
<msti> : STP bridge instance no (0-7, CIST=0, MSTI1=1, ...)
<port_list> : Port list or 'all'. Port zero means aggregations.
<path_cost> : STP port path cost (1-200000000) or 'auto'
Default:
auto
Example:
Set MSTI7 in port1
SWITCH/>stp msti port cost 7 1
MSTI Port Path Cost
---- ---- ----------

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
