Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
234
applies.
 Enabled
Enable the RADIUS Accounting Server by checking this box.
 IP Address/Hostname
The IP address or hostname of the RADIUS Accounting Server. IP address is
expressed in dotted decimal notation.
 Port
The UDP port to use on the RADIUS Accounting Server. If the port is set to 0
(zero), the defa
ult port (1813) is used on the RADIUS Accounting Server.
 Secret
The secret - up to 29 characters long - shared between the RADIUS Accounting
Server and the switch.
TACACS+ Authentication Server Configuration
The table has one row for each TACACS+ Authentication Server and a number of columns, which are:
Object Description
 #
The TACACS+ Authentication Server number for which the configuration below
applies.
 Enabled
Enable the TACACS+ Authentication Server by checking this box.
 IP Address/Hostname
The IP address or hostname of the TACACS+ Authentication Server. IP address
is expressed in dotted decimal notation.
 Port
The TCP port to use on the TACACS+ Authenticati
on Server. If the port is set to 0
(zero), the default port (49) is used on the TACACS+ Authentication Server.
 Secret
The secret - up to 29 characters long - shared between the TACACS+
Authentication Server and the switch.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
