Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
241
Rx
Bad
Authenticators
radiusAcctClientExt
BadAuthenticators
The number of RADIUS
packets containing invalid
authenticators received from
the server.
Rx
Unknown Types
radiusAccClientExt
UnknownTypes
The number of RADIUS
packets of unknown types that
were received from the server
on the accounting port.
Rx
Packets Dropped
radiusAccClientExt
PacketsDropped
The number of RADIUS
packets that were received
from the server on the
accounting port and dropped
for some other reason.
Tx
Requests
radiusAccClientExt
Requests
The number of RADIUS
packets sent to the server.
This does not include
retransmissions.
Tx
Retransmissions
radiusAccClientExt
Retransmissions
The number of RADIUS
packets retransmitted to the
RADIUS accounting server.
Tx
Pending
Requests
radiusAccClientExt
PendingRequests
The number of RADIUS
packets destined for the server
that have not yet timed out or
received a response. This
variable is incremented when
a Request is sent and
decremented due to receipt of
a Response, timeout, or
retransmission.
Tx
Timeouts
radiusAccClientExt
Timeouts
The number of accounting
timeouts to the server. After a
timeout, the client may retry to
the same server, send to a
different server, or give up. A
retry to the same server is
counted as a retransmit as
well as a timeout. A send to a

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
