User’s Manual of MGSW-24160F

252

The page includes the following fields:

System Configuration

Object Description

 Mode

Indicates if Limit Control is globally enabled or disabled on the switch. If globally

disabled, other modules may still use the underlying functionality, but limit checks

and corresponding actions are disabled.

 Aging Enabled

If checked, secured MAC addresses are subject to aging as discussed under

Aging Period.

 Aging Period

If Aging Enabled is checked, then the aging peri

od is controlled with this input. If

other modules are using the underlying port security for securing MAC

addresses, they may have other requirements to the aging period. The

underlying port security will use the shorter requested aging period of all modules

that use the functionality.

The Aging Period can be set to a number between 10 and 10,000,000 seconds.

To understand why aging may be desired, consider the following scenario:

Suppose an end-host is connected to a 3rd party switch or hub, which in turn is

connected to a port on this switch on which Limit Control is enabled. The

end-host will be allowed to forward if the limit is not exceeded. Now suppose that

the end-host logs off or powers down. If it weren’t for aging, the end-host would

still take up resources on this switch and will be allowed to forward. To overcome

this situation, enable aging. With aging enabled, a timer is started once the

end-host gets secured. When the timer expires, the switch starts looking for

frames from the end-host, and if such frames are not seen within the next Aging

Period, the end-host is assumed to disconnect, and the corresponding resources

are freed on the switch.

Port Configuration

The table has one row for each port on the selected switch, which are:

Object Description

 Port

The port number for which the configuration below applies.

 Mode

Controls whether Limit Control is enabled on this port. Both this and the Global

Mode must be

set to Enabled for Limit Control to be in effect. Notice that other

modules may still use the underlying port security features without enabling Limit

Control on a given port.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
