User’s Manual of MGSW-24160F

286

support multiple VLANs, if at all, and are typically configured to use an 'untagged’

VLAN or a single 'tagged’ data specific VLAN. When a network policy is defined

for use with an 'untagged’ VLAN (see Tagged flag below), then the L2 priority

field is ignored and only the DSCP value has relevance.

Video Conferencing

Streaming Video - for use by broadcast or multicast based video content

distribution and other similar applications supporting streaming video services

that require specific network policy treatment. Video applications relying on TCP

with buffering would not be an intended use of this application type.

Video Signaling (conditional) - for use in network topologies that require a

separate policy for the video signaling than for the video media. This application

type should not be advertised if all the same network policies apply as those

advertised in the Video Conferencing application policy.

 Tag

Tag indicating whether the specified application type is using a 'tagged’ or an

'untagged’ VLAN.

Untagged indicates that the device is using an untagged frame format and as

such does not include a tag header as defined by IEEE 802.1Q-2003. In this

case, both the VLAN ID and the Layer 2 priority fields are ignored and only the

DSCP value has relevance.

Tagged indicates that the device is using the IEEE 802.1Q tagged frame format,

and that both the VLAN ID and the Layer 2 priority values are being used, as well

as the DSCP value. The tagged format includes an additional field, known as the

tag header. The tagged frame format also includes priority tagged frames as

defined by IEEE 802.1Q-2003.

 VLAN ID

VLAN identifier (VID) for the port as defined in IEEE 802.1Q-2003

 L2 Priority

L2 Priority is the Layer 2 priority to be used for the specified application type. L2

Priority may specify one of eight priority levels (0 through 7), as defined by IEEE

802.1D-2004. A value of 0 represents use of the default priority as defined in

IEEE 802.1D-2004.

 DSCP

DSCP value to be used to provide Diffserv node behavior for the specified

application type as defined in IETF RFC 2474. DSCP may contain one of 64

code point values (0 through 63). A value of 0 represents use of the default

DSCP value as defined in RFC 2475.

Port Policies Configuration

Every port may advertise a unique set of network policies or different attributes for the same network policies, based on the

authenticated user identity or port configuration.

Object Description

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
