Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
63
 Receive Missing
Remote ID
The packets number that received packets which Remote ID option was missing.
 Receive Bad Circuit ID
The packets number that the Circuit ID option did not match known the circuit ID.
 Receive Bad Remote
ID
The packets number that the Remote ID option did not match the known Remote
ID.
Client Statistics
Object Description
 Transmit to Client
The packets number that relayed packets from server to client.
 Transmit Error
The packets number that error sending packets to servers.
 Receive form Client
The packets number that received packets from server.
 Receive Agent Option
The packets number that received packets with relay agent information option.
 Replace Agent Option
The packets number that replaced received packets with relay agent information
option.
 Keep Agent Optin
The packets number that keepped received packets with relay agent information
option.
 Drop Agent Option
The packets number that dropped received packets with relay agent information
option.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page; any changes made locally will be undone.
: Clear all statistics.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
