G-2
MacBAT 5 – USER GUIDE. Version 1.0
Device can be equipped with backup battery of following parameters:
Voltage: 3,6V
General capacity: 1,2Ah
Type: SAFT LS14250, ½-AA size
Its main functionality is to keep the device operational when the main battery is empty and it has no sufficient energy for keeping the
device functionalities stable. Backup battery is responsible for powering the memory to keep the settings and clock. It is not used while
the main batteries are operating.
Replacement of this battery can be done in Manufacturers technical facility. Replacing battery by oneself will cause loss
of warranty or MID conformity check. It is necessary to remove the plastic cover inside the device housing.
