E-9
MacBAT 5 – USER GUIDE. Version 1.0
To setup the gas composition:
• Go to Main menu by pressing enter
• Navigate to menu Gas and conversion → Gas composition
Case I: simplified gas composition
Gas and conversion → Gas composition → Simplified
Case II: full gas composition
Gas and conversion → Gas composition → Full
Press Enter on each parameter to change its value.
First parameter visible in the menu is GasProc – this parameter
relates to new gas composition percentage consistence.
Press Enter on each parameter to set the new value.
Remember – each value must be changed.
When new gas parameters will be uploaded GasProc must equal 100
+/- deviation from 100% set in Gas and conversion → Gas
composition → Advanced → GasNorm
It is highly recommended to set gas composition using software. Keyboard allows for configuration of gas composition,
however the process is time consuming. Manufacturer suggest to use software for taking these steps in configuration.
