Plum MacBAT 5 - Digital Inputs Configuration

E-13
MacBAT 5 – USER GUIDE. Version 1.0
Introduction:
Device is equipped with up to 8 digital inputs which can be adapted as the counters input or binary inputs for gas station supervisory. Some
of the inputs are shared with the following counters options, then they cannot be used as the digital input.
DI1
binary
DI2
binary
DI3
binary
DI4
binary
DI5
binary
DI6
Namur
DI7
Namur
DI8
binary
LF
X
X
HF
X
X
SCR
X
EN
X
TS
X
Example: input configuration is set to LF1/HF1.
Available inputs to be used as DI: 1-2-4-5-7-8
Tamper switch is configured by default on DI5 by Manufacturer.
To setup the digital inputs:
• Go to Main menu by pressing Enter
• Navigate to menu Inputs/Outputs → Digital inputs → Configuration
• Press Enter on parameter p1subst to perform changes
Available parameters:
• DIOn – status of currently available digital inputs – read only.
• ConfDI – parameter responsible for turning on DIs in the system. Slide left – input turned off. Slide right – input turned on.
• DIPol – determining polarity of the input. Slide left – DI normally closed. Slide right – DI normally opened.
