MacBAT 5 – USER GUIDE. Version 1.0
External power supply (POWER SUPPLY) – Terminals 2 (VIN) to 1 (GND):
Ui=6,51V; Pi=3,5W; Ii=1,1A; Li=0; Ci=12µF
External power supply of communication ports (COM SUPPLY) – Terminals 4 (VIN) to 3 (GND)
Ui=6,51V; Pi=0,8W; Ii=0,4A; Li=0; Ci=2,64µF
Port COM1 – Terminals 5 (D-), 6 (D+) to GND
Port COM2 – Terminals 7 (D-, Rx), 8 (D+, Tx) to GND
Uo=6,51V; Io=0,8A; Po=1,1W; Pi=0,66W; Li=0; Ci=0
Gas Group IIA: Lo=800µH; Co=500µF
Gas Group IIB: Lo=200µH; Co=25µF
External DIGITAL SENSOR – Terminals 10 (VOUT) to 9 (GND)
Uo=6,51V; Io=0,29A; Po=0,47W; Li=0; Ci=0
Gas Group IIA: Lo=2mH; Co=500µF
Gas Group IIB: Lo=1mH; Co=25µF
Outputs DIGITAL OUTPUTS – Terminals 11 (DO1+), 12 (DO2+), 13 (DO3+), 14 (DO4+)
Ui=15V; Ii=0,123A; Pi=0,33W; Li=0; Ci=0; Uo=6,51V
Gas Group IIA: Lo=18mH; Co=7µF
Gas Group IIB: Lo=10mH; Co=1,7µF
Contact inputs – Terminals 16 (DI1+), 18 (DI2+), 20 (DI3+), 22 (DI4+), 24 (DI5+) to GND and 26 (DI6+), 28 (DI7+), 30 (DI8+), 29
(DI8-) to GND
Ui=6,51V; Li=0; Ci=120nF
Gas Group IIA: Lo=800mH; Co=500µF
Gas Group IIB: Lo=400mH; Co=25µF
Additionally only for contact input – Terminal 24 (DI5+) to GND
Po=27mW; Uo=6,51V; Io=16,5mA
