MacBAT 5 – USER GUIDE. Version 1.0
Installation of the device requires set of various tools to perform the process correctly. Below it is listed what tools are required and what
is their purpose in the process of installation:
Tightening the cable glands, pressure sensors ports. Remember to have various sizes of spanners and
additionally one adjustable
Opening and closing device housing
Releasing the buttons in device 5 terminals to lock the wire inside the terminal
Tightening the screws in INT-S3 to secure rigidly the wires
5mm – to tighten the device 5 to mounting plate, to tighten the three-way valve to the mounting plate
Crimping tool for insulation sleeves in the end of the wires
Remember to use safe tools when performing installation in vicinity of gas atmosphere
