MacBAT 5 – USER GUIDE. Version 1.0
Introduction:
Device is equipped with up to 4 digital outputs which can be used as binary – single pulses released when certain alarm, or group of alarms
are active. Counter outputs – each increment of gas volume or flow makes the device
To setup the digital outputs:
• Go to Main menu by pressing Enter
• Navigate to menu Inputs/Outputs → Digital outputs → DO1/DO2/DO3/DO4
• Press Enter on parameters to change their values:
Available options based on DO2:
• DO2Mode – Event, Counter, Frequency. Determine the work mode of the output
• DO2Idx – related to Counter mode. Choice of counter corresponding to pulses on the output
• DO2Evt – related to Event mode. Choice of events code from events table – see the auxiliary document Data Structure
• DO2EvtTm – related to Event mode. Time of pulse lasting
• DO2PulseLen – related to Binary/Event/Counter mode. Length of the pulse in milliseconds
• DO2PulsePer – related to Binary/Event/Counter mode. Time between pulses in milliseconds
• DO2Factor – related to Counter mode. Pulse output factor. Example, value 1. 1 pulse per 1m
3
• DO2Fidx – related to Frequency mode. Determination of parameter corresponding to output frequency.
• DO2Fmin/Fmax – related to Frequency mode. Setting the frequency range on the output.
• Fmin/Fmax – related to Frequency mode. Setting the value of frequency corresponding to min and max values of parameter set in
DO2Fidx.
