Plum MacBAT 5 - General Data

B-4
MacBAT 5 – USER GUIDE. Version 1.0
APPROVALS
ATEX approval
EN IEC 60079-0:2018,
EN 60079-11:2012
FTZÚ 17 ATEX 0047X dated 26.03.2018 and supplementary EU-Type Examination Certificate No. 1 dated
17.12.2019
Ex classification: II 1G Ex ia IIB T4 Ga
Metrology approval
EN 12405-1:2005 + A2:2010
EN 12405-1:2018
EN 12405-2:2012
EU type examination, report no.: PTB-1.42-4101059 and issued the certificates no.:
DE-19-MI002-PTB004 – PTZ converter
DE-19-MI002-PTB005 – T converter
DE-19-M-PTB0032 – load recorder
MacBAT 5 is designed to work in compliance with System 2 specification of EN 12405-2:2012
DIMENSIONS
POLYCARBONATE
ALUMINIUM
Width
196mm / 207mm incl. pressure sensor thread
180mm / 202 mm incl. pressure sensor thread
Height
170mm / 194 mm incl. cable glands
150mm / 167mm incl. cable glands
Depth
77mm
93mm
Weight
1,3kg
3,5kg
ENVIRONMENTAL CONDITIONS
Housing ingress protection
IP66 for outdoor installations
Environmental temperatures
range
-25⁰C to +70⁰C using SAFT LS33600 or TADIRAN SL2780 battery
Od -25⁰C do +70⁰C using EVE 34165 batteries
Electric and magnetic conditions
resistance
M2 – unit can be installed in places exposed for vibrations and flickers
E2 – unit can be installed in places exposed for electrical disturbances in the industry
Relative humidity
Maximum 95% in temperature 70°C
OVERALL
Display
4 inch display with backlight, 128x64 resolution.
Display resistant to the critical low temperatures – from -20 to +70 C degrees
Keyboard
6 pushbuttons in polycarbonate version. 18 pushbuttons in aluminium version.
Circuits connections
1xM16 cable gland (cable diameter 4÷8mm), 8xM14 cable glands (cable diameter 3÷6,5mm)
Antenna connection (optional) – FME-M socket – capable to connect FME-F antenna
Extras
Terminals chamber backlight in aluminium housing variant
