MacBAT 5 – USER GUIDE. Version 1.0
COMMUNICATION WITH THE DEVICE
2x RS485 Ex communication ports (COM1, COM2)
Transmission speed – from 2400b/s up to 256000b/s
Option:
1x RS232 communication port (COM1, instead of RS485) – transmission speed up to 115200b/s
Optical interface IEC 62056-21 (COM3)
Transmission speed – from 9600 to 38400b/s
NFC interface for contactless configuration with MacBAT 5 using Android configuration tool
Internal modem as an option:
• 3G/2G modem
• 4G/3G/2G modem
• NB-IoT/LTE Cat. M1/2G modem
Supplied from installed batteries
MODBUS RTU, MODBUS TCP (in version with internal modem), MODBUS RTU (MASTER MODE),
GAZMODEM, GAZMODEM (MASTER MODE). Other protocols can be used on request.
Voltage: 3,6V
General capacity: 17Ah
Type: SAFT LS33600 – environmental temperature range available: -25 to 70 C degrees
Type: EVE ER34615 – environmental temperature range available: -25 to 50 C degrees
Battery amount: 1 to supply EVC
Estimated lifetime: 5 years, assuming:
• Registration period set on 60 min.
• All of outputs, signalization inputs and transmission ports (wire without terminators) are
inactive;
• LCD display is constantly switched off, keyboard not used;
• Operating temperature equals minimum of ambience temperature, -25° C;
• Provided maximum pulses frequency on LF input (2 Hz);
• Measured gas pressure p1=p1max;
• Measured gas temperature t=tmin;
