Plum MacBAT 5 - Device Types and Accessories

B-3
MacBAT 5 – USER GUIDE. Version 1.0
MacBAT 5 can be assembled in two versions of housing, with various types of pressure sensors, with or without MID Declaration of
Conformity. Basic table of variants is presented below with description of each value.
POLYCARBONATE
Features:
• MID declaration of conformity
• Up to 2 pressure sensors –
internal or external
• Pt1000 temperature sensor,
50mm fixed or adjustable
140-180mm
• Optional internal modem
• Dedicated mounting plate
ALUMINIUM
Features:
• MID declaration of conformity
• Up to 2 pressure sensors –
internal or external
• Pt1000 temperature sensor,
50mm fixed or adjustable
140-180mm
• Optional internal modem
• Dedicated mounting plate
• Full numeric keyboard
• Internal chamber backlight
• Piano black details
Not every combination of pressure sensor assembly can be obtained in the devices assembled with MID Declaration of
Conformity. Example – P1&P2 external sensors are not possible.
