MacBAT 5 – USER GUIDE. Version 1.0
First option to set should be settings for power supply mode. There are two available modes for supplying the device, which are described
below:
• BATT – battery mode, no telemetry equipment, standalone device, no power supply, locally read or through integrated modem in
schedules mode. Features of this mode:
o RS485 ports inactive – temporary work of COM1 is available on battery when the device housing is opened – active alarm
Case Open – purpose is configuration on site
o Digital Outputs work only as the binary, state refreshed every 60 seconds
o HF counters are unavailable – DI6 and DI7 can work only as the NAMUR state inputs
o Device measurement cycle is adjustable from 6 to 60 seconds
o Modem operational only in Schedules mode
• FULL – external power supply mode, connection to INT-S3 or full telemetry cabinet, unlimited device readout and configuration via
modem or serial transmission ports
o RS485 ports active all the time
o Digital Outputs work in every mode, refreshing rate up to 1 second
o HF counters available all the time
o Device measurement cycle is adjustable from 1 to 60 seconds
o Modem operational in every mode
To setup the power supply mode:
• Go to Main menu by pressing Enter
• Navigate to menu Configuration → Power source → External
• Press enter on parameter EPwrSMode and choose proper option: BATT/FULL
There is possibility to sustain FULL mode on batteries while mains power supply failures and there is temporary blackout.
In the same menu find parameter: EPwrSSupp. This parameter range is 0-180 [minutes]. This mode is temporary due
to significant energy consumption while powering the device fully. Battery discharging rate is 0,3% per hour.
