H-2
MacBAT 5 – USER GUIDE. Version 1.0
Once installed, device does not require special actions and supervision. Proper installation guarantees uninterruptible work of the device
within its full lifetime. Device requires only periodical examination according to EN 60079-17 standard.
Periodical examination frequency: minimum once a year. Close eye inspection required.
Spontaneous examination frequency: adjusted depending on environmental conditions. Detailed close eye inspection required.
In some certain conditions device can work improperly, due to lasting alarms or configuration mistakes. In the table there are presented
most common appearing malfunctions with reasons and solutions for these.
Lack of power supply
Battery divider still present
Re-enter the battery in the device
Ensure the divider had been removed
Device does not measure
pressure/temperature
Pressure temperature over the range
Install the device in the field where sensors
ranges are sufficient
Replace the device with different range
sensors
Despite connected power supply device
remains in battery mode
Insufficient power supply source
Check if the power supply source is
compatible with the device.
Check in the events list if there is event
“Insufficient power source”.
Replace power source to the one compatible
and working
Device does not communicate through
optical interface
Optical port in device inactive
Optical head inactive
Optical head malfunction
Wrong baudrate set
Turn on the display
Activate optical interface
Replace optical interface
Ensure baudrate is set correctly
Device does not communicate through
serial ports
Wrong baudrate
Attempt of usage without external power
supply with closed housing
Check baudrate
Open housing, connect to COM1
