MacBAT 5 – USER GUIDE. Version 1.0
For full acknowledgement and understanding of the MacBAT 5 work and maintenance it is necessary to make use of the following documents
in some certain steps, which are mentioned in further part of this document. All the mentioned documents are available to obtain from
manufacturer on request.
• ConfIT! User manual – manual for the ConfIT! software, which is configuration program for MacBAT 5 and other PLUM products
which enables configuration, readout and firmware upgrade of the MacBAT 5
• MacBAT 5 user data structure – document with listed and explained every possible parameters in MacBAT 5 DP table, along with
events list and description
• MacBAT 5 Default ModBUS map – document with listed and explained every possible Modbus registers
• INT-S3 user manual – manual for the INT-S3 which is the signal barrier also utilizing functionality of external power supply source
for MacBAT 5
• OptoBTEx user manual – optical interface for readout and communication
Documents not related to the usage of the product:
• Installation manual – shortened version of user manual focused only on mechanical installation and configuration part
• EU Declaration of Conformity – document confirming approvals for the device
• MID conformity check certificate – document paired with the single device, with the information about test results, uncertainties,
as a final customer approval document
