Plum MacBAT 5 - Page 65

E-7
MacBAT 5 – USER GUIDE. Version 1.0
Ranges of using following algorithms for simplified gas composition:
Parameter
Algorithm
SGERG-88
AGA8-G1
AGA8-G2
AGA NX-19mod
K1=const
XCO2
[%]
0-30
0,15
N/A
XH2
[%]
0-10
N/A
N/A
d
-
0,55-0,9
0,554-0,87
0,554-0,75
0,07-2
Hs
[MJ/m
3
]
20-48
18,7-45,1
N/A
N/A
0-66
XN2
[%]
N/A
0-50
0,15
N/A
K1
-
N/A
0-2
When using algorithms SGERG-88, AGA8-G1, AGA8-G2, AGA NX-19mod and K1=const., device requires programming
of parameters values such as calorific value Hs and relative density d to be adequate for currently set base conditions
(Tb and pb) for volume calculation and reference conditions for combustion (T1 and P1, here always P1=pb). Set of
base conditions in many European countries: pb=1,01325 bar; Tb=273,15 K; T1=298,15 K. When programming full
gas composition, no further recalculations are necessary.
Despite fact, that algorithms AGA8-G2 and AGA NX-19mod are not using calorific value Hs for calculation of
compressibility factor, it must be programmed, because it is necessary for correct computing of energy counter.
